HOT ROD / STREET ROD
COLLECTION
| SERIES |
PART NO. |
SIZE |
BOLT CIRCLE |
BACK SPACE |
PRICE |
| 457 |
457-5510 |
15X5 |
5X4.5, 5X4.75 |
3 |
$132.00 |
| 457 |
457-5610 |
15X6 |
5X4.5, 5X4.75 |
3 3/4 |
$132.00 |
| 457 |
457-56155 |
15X6 |
5X5, 5X5.5 |
3 3/4 |
$132.00 |
| 457 |
457-5710400 |
15X7 |
5X4.5, 5X4.75 |
4 |
$138.00 |
| 457 |
457-5710450 |
15X7 |
5X4.5, 5X4.75 |
4 1/2 |
$138.00 |
| 457 |
457-5715400 |
15X7 |
5X5, 5X5.5 |
4 |
$138.00 |
| 457 |
457-5715450 |
15X7 |
5X5, 5X5.5 |
4 1/2 |
$138.00 |
| 457 |
457-5815400 |
15X8 |
5X4.5, 5X4.75 |
4 |
$143.00 |
| 457 |
457-5815450 |
15X8 |
5X4.5, 5X4.75 |
4 1/2 |
$143.00 |
| 457 |
457-5815400 |
15X8 |
5X5, 5X5.5 |
4 |
$143.00 |
| 457 |
457-5815450 |
15X8 |
5X5, 5X5.5 |
4 1/2 |
$143.00 |
| 457 |
457-5010 |
15X10 |
5X4.5, 5X4.75 |
5 |
$173.00 |
| 457 |
457-5015 |
15X10 |
5X5, 5X5.5 |
5 |
$173.00 |
| 457 |
457-5210 |
15X12 |
5X4.5, 5X4.75 |
4 1/2 |
$243.00 |
| 457 |
457-5215 |
15X12 |
5X5, 5X5.5 |
4 1/2 |
$243.00 |
| 457 |
457-5410 |
15X14 |
5X4.5, 5X4.75 |
4 1/2 |
$260.00 |
| 457 |
457-5415 |
15X14 |
5X5, 5X5.5 |
4 1/2 |
$260.00 |
| SERIES |
PART NO. |
SIZE |
BOLT CIRCLE |
BACK SPACE |
PRICE |
| 457 |
457-7610 |
16X6 |
5X4.5, 5X4.75 |
3 3/4 |
$199.00 |
| 457 |
457-7615 |
16X6 |
5X5, 5X5.5 |
3 3/4 |
$199.00 |
| 457 |
457-7710 |
16X7 |
5X4.5, 5X4.75 |
4 |
$211.00 |
| 457 |
457-7715 |
16X7 |
5X5, 5X5.5 |
4 |
$211.00 |
| 457 |
457-7810 |
16X8 |
5X4.5, 5X4.75 |
4 3/4 |
$211.00 |
| 457 |
457-7815 |
16X8 |
5X5, 5X5.5 |
4 3/4 |
$211.00 |
| 457 |
457-7010 |
16X10 |
5X4.5, 5X4.75 |
5 |
$288.00 |
| 457 |
457-7015 |
16X10 |
5X5, 5X5.5 |
5 |
$288.00 |
| SERIES |
PART NO. |
SIZE |
BOLT CIRCLE |
BACK SPACE |
PRICE |
| 457 |
457-8710 |
17X7 |
5X4.5, 5X4.75 |
4 5/8 |
$329.00 |
| 457 |
457-8715 |
17X7 |
5X5, 5X5.5 |
4 5/8 |
$329.00 |
| 457 |
457-8810 |
17X8 |
5X4.5, 5X4.75 |
4 1/2 |
$356.00 |
| 457 |
457-8815 |
17X8 |
5X5, 5X5.5 |
4 1/2 |
$356.00 |
| 457 |
457-8910 |
17X9 |
5X4.5, 5X4.75 |
5 1/2 |
$384.00 |
| 457 |
457-8915 |
17X9 |
5X5, 5X5.5 |
5 1/2 |
$384.00 |
|
STANDARD |
REVERSE |
| SIZE |
NEGATIVE |
POSITIVE |
NEGATIVE |
POSITIVE |
| 15X5 |
3 |
3 1/2 |
2 |
2 1/2 |
| 15X6 |
3 1/2 |
4 1/2 |
2 1/8 |
3 1/4 |
| 15X7 |
4 |
5 1/4 |
2 1/4 |
3 1/2 |
| 15X8 |
4 |
6 1/4 |
2 1/4 |
4 1/2 |
| 15X10 |
4 1/4 |
8 |
2 1/2 |
6 |
| 15X12 |
4 1/4 |
10 |
2 1/2 |
8 |
| 15X14 |
4 1/4 |
11 1/2 |
2 1/2 |
10 |
| 16X6 |
3 1/2 |
4 1/2 |
2 1/2 |
3 1/4 |
| 16X7 |
4 |
5 1/4 |
2 1/4 |
3 1/2 |
| 16X8 |
4 3/4 |
6 |
2 1/4 |
3 1/2 |
| 16X10 |
4 1/4 |
7 1/2 |
2 1/2 |
6 |
| 17X7 |
3 3/4 |
5 3/4 |
2 3/4 |
4 3/4 |
| 17X8 |
4 1/2 |
6 3/4 |
2 3/4 |
5 |
| 17X9 |
5 1/2 |
7 3/4 |
2 3/4 |
5 1/4 |
NOTE: There is an additional $20 fee for Custom Backspaces.
- Two piece, all-steel construction.
- Offered in multi fit and direct fit. See the above Tables or Contact Us for details
- Center cap and trim ring are not included, order separately. See the Caps and Trim Rings page for accessories.
- Requires conical seat lug nut (Acorn), not included.
- Custom backspace available. Contact Us for details.
- Inside knob for cap is 8 1/8".
- Wheels primered $15.00 each.
- ALL SALES FINAL
